FX1S Series Programmable Controllers Installation Notes 3
3-10
1) Handle the crimp terminal of the following size when 1 wire is used per terminal. Refer to
Figure 3.5 for installation instructions.
Figure 3.4: Crimp Terminal for M3 Screws
Figure 3.5: Installing 1 wire Per a Terminal
6.2 mm (0.24" )
or less
φ
3.2 (0.13")
6.2 mm (0.24")
or less
φ
3.2 (0.13")
Terminal
Terminal
screw
Crimp
terminal
