Mitsubishi FX1S Series Hardware Manual

FX1S Series Programmable Controllers Introduction 1
1-11
1
2
3
4
5
6
7
1.4.1 Note for Using Expansion Board
The following conditions cannot be accomplished with an FX
1S
PLC.
-FX
1N
-422-BD + FX-2PIF
-FX
1N
-5DM + FX
1N
-422-BD + FX-10DM
-FX-10DM + FX
1N
-422-BD + FX-10DM
- Connect two Programming tools (FX-10P-E, FX-20P-E, Programming software, etc.)
- The use of Special function Blocks
Caution
Connect a programming tool (such as an FX-10P-E, FX-20P-E and personal computer) to
either the connector built in to the PLC or the connector on the FX
1N
-422-BD or FX
1N
-232-
BD. If a programming tool is connected to both connectors, the program stored in the PLC
may not match the program stored in the programming tool. If the program is changed or the
set value of timers or counters are changed with this configuration, the program may be par-
tially overwritten and the PLC may malfunction.

Mitsubishi FX1S Series Specifications

General

Model	FX1S Series
I/O Points	10 to 30 points
Program Memory	2000 steps
Power Supply	AC
Communication	RS-422
Expansion	No expansion
Programming Language	Ladder Logic
Input Voltage	100-240V AC
Built-in High-Speed Counter	Up to 60 kHz (single-phase)
Weight	Approx. 0.3 kg
Dimensions	90 x 60 x 75 mm
