7. Diagnostics
7.1 Preliminary Checks
Table 7.1: Preliminary Checks
Check power supply, ground and I/O cables are wired correctly.
Turn the power supply on. Check that the power LED is lit. Down load a
small test program to the PLC. Verify the program to ensure it has been
written to the PLC correctly. Using the programming device, force each
output ON/OFF. Check the output LEDs for operation.
Put the PLC into RUN. Check the RUN LED is lit. Check that the previously
down loaded program works correctly. Once all checks are complete take
the PLC out of run and turn OFF the power supply.
During this testing stage take extreme care not to touch any live or
hazardous parts.
POWER
RUN
ERROR
POWER
RUN
ERROR
POWER
RUN
ERROR

Mitsubishi FX1S Series Specifications

General

Model	FX1S Series
I/O Points	10 to 30 points
Program Memory	2000 steps
Power Supply	AC
Communication	RS-422
Expansion	No expansion
Programming Language	Ladder Logic
Input Voltage	100-240V AC
Built-in High-Speed Counter	Up to 60 kHz (single-phase)
Weight	Approx. 0.3 kg
Dimensions	90 x 60 x 75 mm
