Mitsubishi FX1S Series Hardware Manual

FX1S Series Programmable Controllers Power Supply 4
4-1
1
2
3
4
5
6
7
4. Power Supply
4.1 Wiring Techniques
Wiring for FX
1S
products has been designed to be safe and easy. If the user is concerned
about the correct installation of these products or associated products, please contact a
professional electrician who is trained to the local and national standards applicable to the
installation site.
4.2 Wiring Cautions
• Do not run input signals in the same multicore cable as output signals or allow them to
share the same wire.
• Do not lay I/O signal cables next to power cables or allow them to share the same trunking
duct. Low voltage cables should be reliably separated or insulated with regard to high
voltage cabling.
• Where I/O signal lines are used over an extended distance consideration for voltage drop
and noise interference should be made.

Mitsubishi FX1S Series Specifications

General

Model	FX1S Series
I/O Points	10 to 30 points
Program Memory	2000 steps
Power Supply	AC
Communication	RS-422
Expansion	No expansion
Programming Language	Ladder Logic
Input Voltage	100-240V AC
Built-in High-Speed Counter	Up to 60 kHz (single-phase)
Weight	Approx. 0.3 kg
Dimensions	90 x 60 x 75 mm
