Mitsubishi FX1S Series Hardware Manual

FX1S Series Programmable Controllers Diagnostics 7
7-7
1
2
3
4
5
6
7
7.8 Error Codes
Table 7.6: Error Codes
D8061
Check cable connections
No error0000
RAM error6101
Operation circuit error6102
I/O bus error (M8069 = ON)6103
D8062
Check the programmer / PLC
connections
No error0000
Parity/overrun/framing error6201
Character error6202
Data sum check error6203
Data format error6204
Command error6205
D8063
Check both power and
communications connections
No error0000
Parity/overrun/framing error6301
Character error6302
Data sum check error6303
Data format error6304
Command error6305
Watchdog timer error6306

Mitsubishi FX1S Series Specifications

General

Model	FX1S Series
I/O Points	10 to 30 points
Program Memory	2000 steps
Power Supply	AC
Communication	RS-422
Expansion	No expansion
Programming Language	Ladder Logic
Input Voltage	100-240V AC
Built-in High-Speed Counter	Up to 60 kHz (single-phase)
Weight	Approx. 0.3 kg
Dimensions	90 x 60 x 75 mm
