FX1S Series Programmable Controllers Diagnostics 7
7-11
1
2
3
4
5
6
7
7.10 Device List
Table 7.9: Device List
Device Type Specification Remarks
Program capacity
2k steps by FX1S internal EEPROM
or
2k steps by FX
1N
-EEPROM-8L
I/O configuration Max total I/O set by Main Processing Unit
Auxiliary relay
(M coils)
General 384 points M0 to M383
Latched
(EEPROM
backed-up)
128 points M384 to M511
Special 256 points From the range M8000 to M8255
State relays
(S coils)
Latched
(EEPROM
backed-up)
128 points S0 to S127
Initial 10 points (subset) S0 to S9
Timers (T)
100 msec
63 points
Range: 0 to 3,276.7 sec
T0 to T62
10 msec
31 points
Range: 0 to 327.67 sec
T32 to T62 when special M coil
M8028 is driven ON
1 msec
1 point
Range: 0.001 to 32.767 sec
T63

Mitsubishi FX1S Series Specifications

General

Model	FX1S Series
I/O Points	10 to 30 points
Program Memory	2000 steps
Power Supply	AC
Communication	RS-422
Expansion	No expansion
Programming Language	Ladder Logic
Input Voltage	100-240V AC
Built-in High-Speed Counter	Up to 60 kHz (single-phase)
Weight	Approx. 0.3 kg
Dimensions	90 x 60 x 75 mm
