Mitsubishi FX1S Series Hardware Manual

FX1S Series Programmable Controllers Power Supply 4
4-6
4.6 Service Power supply
An AC powered FX
1S
can supply a service current of 24V DC at 400mA.
A DC powered FX
1S
does not have the capacity to supply a service current.
4.7 Earthing / Grounding
Use a cable at least 0.2mm
2
(AWG24) to ground equipment. Ground resistance must be less
than 100
Ω
. Note that the ground cable must not be connected to the same ground as the
power circuits.

Mitsubishi FX1S Series Specifications

General

Model	FX1S Series
I/O Points	10 to 30 points
Program Memory	2000 steps
Power Supply	AC
Communication	RS-422
Expansion	No expansion
Programming Language	Ladder Logic
Input Voltage	100-240V AC
Built-in High-Speed Counter	Up to 60 kHz (single-phase)
Weight	Approx. 0.3 kg
Dimensions	90 x 60 x 75 mm
