4.3 Power Supply
• When wiring an AC supply, the “Live” cable should be connected to the “L” terminal and
the “Neutral” cable should be connected to the “N” terminal. Do NOT connect the “Live”
wire to the “N” terminal, otherwise, the user may receive a dangerous shock upon
powerup.
• When wiring a DC supply, the “Live” cable should be connected to the “+” terminal and
the “Neutral” cable should be connected to the “-” terminal. Do NOT connect the “Live”
wire to the “-” terminal, otherwise, the user may receive a dangerous shock upon
powerup.
