FX1S Series Programmable Controllers Outputs 6
6-1
1
2
3
4
5
6
7
6. Outputs
6.1 Output Specifications
Table 6.1: Output Specifications
Description Relay Output Transistor Output
Switched voltages (resistive load)
≤
240V AC,
≤
30V DC
5 - 30V DC
Rated current / N points
(resistive load)
2A/1 point, 8A/COM 0.5A/1 point, 0.8A/COM
Max. Inductive load
80VA, 120/240 VAC,
See table 6.2 for more details
12W/24V DC
Max. Lamp load (tungsten load)
100W
(1.17A/85V AC, 0.4A/250V AC)
0.9W/24V DC
Minimum load
When supply voltage < 5V DC
allow at least 2mA flow
-
Response time
(approx.)
OFF
➔
ON
10ms < 0.2ms; <5
µ
s (Y0,Y1 only)
ON
➔
OFF
10ms
< 0.2ms (I > 0.2 A); <5
µ
s (Y0,Y1
only)
Circuit isolation
By Relay PhotoCoupler
Open circuit current leakage
- 0.1mA/30V DC
Operation indication
LED is lit when coil is energized
Output protection
Internal device
None
Outside device
(Fuse)
Rated value according to the load.
