Mitsubishi FX1S Series Hardware Manual

FX1S Series Programmable Controllers Power Supply 4
4-3
1
2
3
4
5
6
7
4.4 Power Supply Characteristics
*1 Includes the input current (5 or 7mA per point).
Table 4.2: DC Input Power Requirements, FX
1S
-**M*-DS, DSS
0
*1 Includes the input current (5 or 7mA per point).
Table 4.1: AC Input Power Requirements, FX
1S
-**M*-ES/UL, ESS/UL
Description FX
1S
-10M FX
1S
-14M FX
1S
-20M FX
1S
-30M
Power supply 100 - 240V AC, +10% -15%, 50/60 Hz
Max. allowable momentary
power failure period
10ms; if less than 10ms, the PLC will continue operation.
If 10ms or more, the PLC will shut down
Fuse (size) rating 250V 1.0A
In-rush current
100V AC - Max. 15A for 5ms
200V AC - Max. 25A for 5ms
Power consumption 19W
*1
19W
*1
20W
*1
21W
*1
24V DC Service Supply 400 mA
Description FX
1S
-10M FX
1S
-14M FX
1S
-20M FX
1S
-30M
Power supply 24 V DC +10% -15%
Max. allowable momentary
power failure period
5 ms; If less than 5 ms, the PLC will continue operation.
If 5 ms or more, the PLC will shut down
Fuse rating 0.8A
In-rush current 15A for 0.1 ms
Power consumption
*1
6W 6.5W 7W 8W

Mitsubishi FX1S Series Specifications

General

Model	FX1S Series
I/O Points	10 to 30 points
Program Memory	2000 steps
Power Supply	AC
Communication	RS-422
Expansion	No expansion
Programming Language	Ladder Logic
Input Voltage	100-240V AC
Built-in High-Speed Counter	Up to 60 kHz (single-phase)
Weight	Approx. 0.3 kg
Dimensions	90 x 60 x 75 mm
