Mitsubishi FX1S Series Hardware Manual

FX1S Series Programmable Controllers Introduction 1
1-10
Table 1.9: Configuration Notes
A
FX
1S
Series Main Unit
B
FX
1N
Expansion Boards for Analog I/O
C
FX
1N
Expansion Boards without Analog I/O
D
Memory Cassette or Display Module
E
Programming Software
F
RS-232C/RS-422 Converter for PC
G
Dedicated Programming Tools
H
HMI Devices (GOT-F900/ GOT-A900/ DM/ DU)
<GOT: Graphic Operation Terminal, DM: Display Module, DU: Data access Unit>
H'
DU Series (Discontinued since Sept. 2002)
Table 1.10: Connection Ports
1
Left hand side port
1'
Left hand side port + FX
1N
-232-BD
or
Left hand side port + FX
1N
-CNV-BD + FX
2NC
-232ADP
or
Left hand side port + FX
1N
-CNV-BD + FX
0N
-232ADP
1"
Left hand side port + FX
1N
-422-BD
2
Programming Port

Mitsubishi FX1S Series Specifications

General

Model	FX1S Series
I/O Points	10 to 30 points
Program Memory	2000 steps
Power Supply	AC
Communication	RS-422
Expansion	No expansion
Programming Language	Ladder Logic
Input Voltage	100-240V AC
Built-in High-Speed Counter	Up to 60 kHz (single-phase)
Weight	Approx. 0.3 kg
Dimensions	90 x 60 x 75 mm
