FX1S Series Programmable Controllers Introduction 1
1-4
*1 The communication adapter needs to connect via an FX
1N
-CNV-BD to the FX
1S
Series
PLC.
Table 1.5: Expansion Board and Communication Adapter
MODEL DESCRIPTION
POWER
SUPPLY
(External
24V DC)
DIMENSIONS
MASS
(WEIGHT)
kg (lbs)
FX
1N
-4EX-BD Four point special input -
Mounts directly into
top of PLC
Mounts
directly into
top of PLC
FX
1N
-2EYT-BD Two point special output -
FX
1N
-2AD-BD Two channel special analog to digital converter -
FX
1N
-1DA-BD One channel special digital to analog converter -
FX
1N
-232-BD RS-232C communication interface -
FX
1N
-422-BD RS-422 communication interface -
FX
1N
-485-BD RS-485 communication interface -
FX
1N
-8AV-BD Analog potentiometer -
FX
1N
-CNV-BD Communication adapter connection interface -
FX
2NC
-232ADP
*1
RS-232C communication adapter -
19.1
(0.76)
90
(3.55)
85
(3.35)
0.1 (0.22)
FX
0N
-232ADP
*1
RS-232C communication adapter -
43
(1.70)
68
(2.68)
FX
2NC
-485ADP
*1
RS-485 communication adapter -
19.1
(0.76)
78
(3.08)
FX
0N
-485ADP
*1
RS-485 communication adapter 50mA
43
(1.70)
87
(3.43)
0.3 (0.66)
