Mitsubishi FX1S Series Hardware Manual

FX1S Series Programmable Controllers Installation Notes 3
3-7
1
2
3
4
5
6
7
• Replace the terminal cover provided, after installation or wiring work is completed, and
before supplying power and operating the unit to avoid electric shock.
• After reading the manual’s safety instructions, initiate the operation for making program
changes while the PLC is in RUN mode, forcing ON/OFF, and switching RUN/STOP.
• DO NOT use the “
●
” terminal in PLC.
• When using an incorrect power source or performing incorrect operation, serious
damage will occur regardless of the level of the voltage and frequency.
• When performing incorrect wiring or operation, serious damage will occur.
• The “L” and “N” terminals are not reversible.
If the “L” and “N” terminals are reversed, the units may be seriously damaged.
• The “24V” and “0V” terminals are not reversible.
If the “24V” and “0V” terminals are reversed, the units may be seriously damaged.
• During transportation avoid any impact as the PLC is a precision instrument.
It is necessary to check the operation of PLC after transportation, in case of any impact
damage.
• When storing the PLC, conform to the environmental conditions specified by the general
specification.

Mitsubishi FX1S Series Specifications

General

Model	FX1S Series
I/O Points	10 to 30 points
Program Memory	2000 steps
Power Supply	AC
Communication	RS-422
Expansion	No expansion
Programming Language	Ladder Logic
Input Voltage	100-240V AC
Built-in High-Speed Counter	Up to 60 kHz (single-phase)
Weight	Approx. 0.3 kg
Dimensions	90 x 60 x 75 mm
