Mitsubishi FX1S Series Hardware Manual

HEAD OFFICE: MITSUBISHI DENKI BLDG MARUNOUCHI TOKYO 100-8310
HIMEJI WORKS: 840, CHIYODA CHO, HIMEJI, JAPAN
JY992D83901H
(MEE)
Effective Jan. 2004
Specifications are subject to change without notice.
HARDWARE MANUAL
FX
1S
SERIES PROGRAMMABLE CONTROLLERS
MODEL
FX1S-HW-E
MODEL CODE
09R510

Mitsubishi FX1S Series Specifications

General

Model	FX1S Series
I/O Points	10 to 30 points
Program Memory	2000 steps
Power Supply	AC
Communication	RS-422
Expansion	No expansion
Programming Language	Ladder Logic
Input Voltage	100-240V AC
Built-in High-Speed Counter	Up to 60 kHz (single-phase)
Weight	Approx. 0.3 kg
Dimensions	90 x 60 x 75 mm
