2 - 2 2 - 2
MELSEC-
2 SYSTEM CONFIGURATION
POINT
(1) The connection order of remote stations is not relevant to the station numbers.
(2) The remote station numbers are not necessarily consecutive. (Empty station
number does not cause data link failure.)
2.2 Applicable System
This section explains the applicable master modules and the precautions for system
configuration.
(1) The following table indicates the applicable master modules.
Model Name
Q series QJ61BT11N, QJ61BT11
QnA series AJ61QBT11, A1SJ61QBT11
A series AJ61BT11, A1SJ61BT11
FX series FX2N-16CCL-M
PCI board Q80BD-J61BT11N, A80BD-J61BT11
Others CC-Link partner maker's master module
The FX series can be used within the range of:
FX
1N, FX1NC 128 points
FX
2N, FX2NC 256 points
in the whole system.
2.2.1 Applicable software package
To carry out CC-Link / CC-link/LT diagnostics, GX Developer of Version 8.00A or later
is required.
