4 - 4 4 - 4
MELSEC-
A
4 PROCEDURE UP TO DATA LINK
4.3 Part Names and Settings
This section explains the part names, LED displays, and setting methods of switch, etc
for the AJ65SBT-CLB.
A
J65SBT-CLB
(FG)
ON
8
ERR. LERR.RUNLLRUN ERR.PW L
NC
BRATENOS
BRATE
STATION NO.
TST
112121241248102040
MODE
456789 12 45
2
67123 10 3
CC-Link/LTCC-Link CC-Link CC-Link/LT
CC-Link/LTCC-Link
1)
Diagram 1
6)
3)
5)
4)
2)
Number Name Description
Shows the module status as the LED on/off.
LED name Description
CC-Link side CC-Link/LT side
PW
On: Module normal
Off: Module fault or not supplied with power
1) LED display
L RUN
On: Data link communication normal
Off: Data link communication off (time-
out)
<During normal operation>
On: Data link being executed
Off: Data link stopped
<In self-loopback test mode>
On: Self-loopback test completed.
Off: Self-loopback test failed
