3 SPECIFICATIONS
3.7 Remote Registers
The AJ65SBT-CLB has the remote registers to make data communication with the
master module.
This section explains the assignment and data structure of the remote registers of the
AJ65SBT-CLB.
3.7.1 Assignment of remote registers
The following tables indicate the assignment of the remote registers.
(1) RWw
Address Remote Register Definition Initial value Reference
RWwn Last station number setting 0 Sec. 3.7.2
RWwn 1 Data link stop/restart instructions 0 Sec. 3.7.3
RWwn 2 Error status flag clear 0 Sec. 3.7.4
RWwn 3
to
RWwn
F
Use prohibited
n: Address assigned to the master station in station number setting.
(2) RWr
(a) When 2 stations are occupied
Address Remote Register Definition Reference
RWrn Data of operating statuses Sec. 3.7.5
RWrn 1 Data of faulty station : Station number 1 to 12 Sec. 3.7.6
RWrn 2 Remote I/O error data :Station number 1 to 12 Sec. 3.7.7
RWrn 3 Data of remote station connection Sec. 3.7.8
RWrn 4 Setting data Sec. 3.7.9
RWrn 5
to
RWrn
7
Use prohibited
n: Address assigned to the master station in station number setting.
(b) When 4 stations are occupied
Address Remote Register Definition Reference
RWrn Data of operating states Sec. 3.7.5
RWrn 1
RWrn 2
Data of faulty station : Station number 1 to 28 Sec. 3.7.6
RWrn 3
RWrn 4
Remote I/O error data :Station number 1 to 28 Sec. 3.7.7
RWrn 5
RWrn 6
Data of remote station connection Sec. 3.7.8
RWrn 7 Setting data Sec. 3.7.9
RWrn 8
to
RWrn
F
Use prohibited
n: Address assigned to the master station in station number setting.
