3 - 10 3 - 10
MELSEC-
3 SPECIFICATIONS
(c) The following table lists the I/O signals for 8 occupied station (4 occupied
stations
2 modules) setting
Remote input (X) of CC-Link/LT Remote input (RX) of
CC-Link
F E D C B A 9 8 7 6 5 4 3 2 1 0
RXnF to RXn0 Station number 4 Station number 3 Station number 2 Station number 1
to to
RX(n 6)F to RX(n 6)0 Station number 28 Station number 27 Station number 26 Station number 25
RX(n 7)F to RX(n 7)0 Use prohibited
RX(n 8)F to RX(n 8)0 Station number 32 Station number 31 Station number 30 Station number 29
to to
RX(n E)F to RX(n E)0 Station number 56 Station number 55 Station number 54 Station number 53
RX(n F)F to RX(n F)0 Use prohibited
Remote output (Y) of CC-Link/LT Remote output (RY) of
CC-Link
F E D C B A 9 8 7 6 5 4 3 2 1 0
RYnF to RYn0 Station number 4 Station number 3 Station number 2 Station number 1
to to
RY(n 6)F to RY(n 6)0 Station number 28 Station number 27 Station number 26 Station number 25
RY(n 7)F to RY(n 7)0 Use prohibited
RY(n 8)F to RY(n 8)0 Station number 32 Station number 31 Station number 30 Station number 29
to to
RY(n E)F to RY(n E)0 Station number 56 Station number 55 Station number 54 Station number 53
RY(n F)F to RY(n F)0 Use prohibited
