Mitsubishi MELSEC User Manual

A - 13
4.2.1 I/O numbers of base unit
4.2.2 I/O numbers of remote station
4.3 I/O Assignment by GX Developer
4.3.1 Purpose of I/O assignment by GX Developer
4.3.2 Concept of I/O assignment using GX Developer
4.3.3 Examples of I/O Number Assignment
4.4 Checking the I/O Numbers
CHAPTER5 MEMORIES AND FILES HANDLED BY CPU MODULE
5.1 Memories by CPU Module
5.1.1 Memory configuration and storable data
5.1.2 Program memory
5.1.3 Standard ROM
5.1.4 Standard ROM program execution (boot run) and writing
5.2 Program File Structure
5.3 File Operation by GX Developer and Handling Precautions
5.3.1 File operation
5.3.2 Precautions for handling files
5.3.3 Memory capacities of files
5.3.4 File size units
CHAPTER6 FUNCTIONS
6.1 Function List
6.2 Safety CPU Operation Mode
6.2.1 Safety CPU operation mode
6.2.2 Checking safety CPU operation mode
6.2.3 Safety CPU operation mode switching
6.2.4 Operation of each function in each safety CPU operation mode and CPU operation status
6.2.5 Online operations that can be executed on the CPU module from GX Developer
6.3 CPU access password
6.4 PLC memory initialization
6.5 Setting to prevent continuous RUN in TEST MODE
6.6 Checking the ROM write count
6.7 Self-diagnostics Function
6.7.1 LED display for error
6.7.2 Cancel the error
6.8 Recording the operation contents and self-diagnostics error occurrence contents (operation
• error
history function)
6.9 Constant scan
6.10 Setting of Output (Y) Status when Changing between STOP and RUN
6.11 Clock Function
6.12 Remote Operation
6.12.1 Remote RUN/STOP
6.12.2 Remote RESET

Mitsubishi MELSEC Specifications

General

Category	Programmable Logic Controller (PLC)
Manufacturer	Mitsubishi Electric
Series	MELSEC
Programming Languages	Ladder Diagram (LD), Function Block Diagram (FBD), Structured Text (ST), Instruction List (IL), Sequential Function Chart (SFC)
Communication Protocols	Ethernet, CC-Link, RS-232, RS-485, USB, Profibus, Modbus
Model Series	FX, Q, L, iQ-R, iQ-F
Input Voltage	100-240V AC, 24V DC (varies by model)
Memory Capacity	Varies widely depending on the CPU module and series. Ranges from kilobytes to megabytes.
I/O Points	16 to 8192 points (varies by model)
Communication Ports	Ethernet, RS-232, RS-485, USB (varies by model)
Programming Software	GX Works2, GX Works3, GX Developer
Operating Temperature	0°C to 55°C
Storage Temperature	-25°C to 75°C
Humidity	5% to 95% (non-condensing)
Vibration Resistance	10 to 57Hz, 0.075mm amplitude; 57 to 150Hz, 9.8m/s² acceleration
Shock Resistance	147m/s², 3 times in each direction (X, Y, Z)
Protection Class	IP20 (varies by model)
CPU Processing Speed	0.02μs to 0.1μs per instruction (varies by model)
