12.3 Error Code List
12.3.8 Error code list (8000 to 9000)
12 - 51
9
EMC AND LOW VOLTAGE DIRECTIVES
10
LOADING AND INSTALLATION
11
MAINTENANCE AND INSPECTION
12
TROUBLESHOOTING APPENDICES INDEX
8060 Error of system programs is detected.
• Take measure against noise.
• Reset it and run it again.
If the same error is displayed again, this
suggests a CPU module hardware fault.
(Contact your local Mitsubishi
representative.)
QS
8070
The initial communication between CPU
A and CPU B was unsuccessful.
• Take measure against noise.
• Reset it and run it again.
If the same error is displayed again, this
suggests a CPU module hardware fault.
(Contact your local Mitsubishi
representative.)
QS
8071
CPU A and CPU B cannot send data to
each other.
8072
CPU A and CPU B cannot receive data
from each other.
8073
CPU A and CPU B cannot send data to
each other.
8074
CPU A and CPU B cannot receive data
from each other.
8080
Power supply voltage error has been
detected in a CPU module.
• Take measure against noise.
• Reset it and run it again.
If the same error is displayed again, this
suggests a CPU module hardware fault.
(Contact your local Mitsubishi
representative.)
QS
8090
The error of line voltage monitoring
circuit is detected.
• Take measure against noise.
• Reset it and run it again.
If the same error is displayed again, this
suggests a CPU module hardware fault.
(Contact your local Mitsubishi
representative.)
QS
8100
The continuous operation time on TEST
MODE exceeds the TEST MODE
continuous operation time set by the
parameter.
Confirm that the safety CPU operation
mode can be switched to the SAFETY
MODE, and start operation after
switching the TEST MODE to the
SAFETY MODE.
QS
8120 Clock stop of the WDT is detected.
• Take measure against noise.
• Reset it and run it again.
If the same error is displayed again, this
suggests a CPU module hardware fault.
(Contact your local Mitsubishi
representative.)
QS
8300
Error information is received from CC-
Link Safety remote station.
Confirm the error code of the relevant
CC-Link Safety remote station. (Refer to
the manual of the CC-Link Safety
remote module for the confirmation.)
QS
Error
Code
(SD0)
Error Contents and Cause Corrective Action
Corresponding
CPU

Mitsubishi MELSEC Specifications

General

Category	Programmable Logic Controller (PLC)
Manufacturer	Mitsubishi Electric
Series	MELSEC
Programming Languages	Ladder Diagram (LD), Function Block Diagram (FBD), Structured Text (ST), Instruction List (IL), Sequential Function Chart (SFC)
Communication Protocols	Ethernet, CC-Link, RS-232, RS-485, USB, Profibus, Modbus
Model Series	FX, Q, L, iQ-R, iQ-F
Input Voltage	100-240V AC, 24V DC (varies by model)
Memory Capacity	Varies widely depending on the CPU module and series. Ranges from kilobytes to megabytes.
I/O Points	16 to 8192 points (varies by model)
Communication Ports	Ethernet, RS-232, RS-485, USB (varies by model)
Programming Software	GX Works2, GX Works3, GX Developer
Operating Temperature	0°C to 55°C
Storage Temperature	-25°C to 75°C
Humidity	5% to 95% (non-condensing)
Vibration Resistance	10 to 57Hz, 0.075mm amplitude; 57 to 150Hz, 9.8m/s² acceleration
Shock Resistance	147m/s², 3 times in each direction (X, Y, Z)
Protection Class	IP20 (varies by model)
CPU Processing Speed	0.02μs to 0.1μs per instruction (varies by model)
