5 PARAMETER SETTINGS
Table 5.1 Remote master station network parameter setting items
Network station type
Parameter setting item
Remote master station
Reference
section
Settings with the network module
—
Section 4.3
Station number (STATION No.) Section 4.3.1
Mode (MODE) Section 4.3.2
Settings with GX Developer
—
Setting the number of module cards (network type) Section 5.1.1
Network settings
—
Section 5.1.2
Starting I/O No. Section 5.1.2 (1)
Network No. Section 5.1.2 (2)
Total stations Section 5.1.2 (3)
Group No. Section 5.1.2 (4)
Mode Section 5.1.2 (5)
Common parameters
—
Section 5.1.3
Send range of each station (LX/LY settings) Section 5.1.3 (1)
Send range of each station (LB/LW settings) Section 5.1.3 (2)
Reserved station settings Section 5.1.3 (3)
Supplemental settings
—
Section 5.1.4
Constant link scan
Maximum number of return stations per scan
Multiplex transmission
Instruction to guarantee send data per station
Instruction to guarantee receive data per station
Transient settings
Refresh parameters Section 5.1.5
Valid module number during other station access Section 5.1.6
Interrupt setting parameters Section 7.7
Redundant settings Section 5.1.7
Routing parameters 3
: Always set : Default setting exists : Set as needed : Setting not required
3: For details, refer to the Q Series MELSECNET/H Network System
Reference Manual (PLC to PLC Network).
REMARK
Always write network parameters to the remote master station.
