5 PARAMETER SETTINGS
5.2 Remote I/O Station Parameter Settings
For remote I/O stations, set up the PLC parameters, network parameters, and remote
password on the remote I/O module as needed.
POINT
After writing the parameters to the remote I/O module, reset it to enable the
parameters that have been set. To reset the remote I/O module, use the reset
switch on the body of the main module or reset the power supply for the remote I/O
station.
5.2.1 Remote I/O station possible parameter settings
The following parameters are set as needed on the remote I/O station and written to
the remote I/O module.
If settings are not needed, the remote I/O station operates using the remote I/O module
default settings so there is no need to write the parameters to the remote I/O module.
(1) PLC parameters
The remote I/O module can set the set the PLC parameters in the same manner
as the CPU module. However, only the required items can be set as a remote
I/O station.
Major item Intermediate item Small item Default value
Number of empty slots Number of empty slots 16 points
PLC system settings
Module synchronization
Synchronizes intelligent module's pulse
up
Synchronizes
Fuse blown Stop
Operation mode upon an error 1
I/O module verification error Stop
Carry out fuse blown check Checks
PLC RAS settings
Error check
Carry out I/O module comparison Checks
Remote I/O switch settings Remote I/O switch settings —
Points/start
Assignment method
Start/End
Start/End
Device name
Points/Start
Operational settings
Forwarding parameter between devices
Start/End
No setting
Type
Model name
Points
I/O assignment
Start
No setting
Base model name
Power model name
Extension cable
Points
I/O assignment
Standard setting
Base mode
No setting
