4 - 5 4 - 5
MELSEC-Q
4 SETUP AND PROCEDURES BEFORE STARTING THE OPERATION
4.2.2 QJ72LP25-25, QJ72LP25G, QJ72LP25GE, QJ72BR15
Setting
0
1 to 64
65 to 99
Valid setting range
Setting error
Setting error
Contents
0
On line
Self return test
Prohibited
Hardware test
Internal self return test
1
2
3
4 to F
4) IN/OUT connector
For connector for optical fiber.
(IN connector)
For forward loop receive/reverse loop send
(OUT connector)
For forward loop send/reverse loop receive
5) MODE (Factory setting: 0): Mode setting switch
Sets the operating mode
a) QJ72LP25G, QJ72LP25GE, QJ72BR15
b) QJ72LP25-25
0
Online
Self return test
Prohibited
Hardware test
Internal self return test
1
2
3
8 to F
10 Mbps
used
4
Online (Parameter mode selection
is enabled)
Self return test
Hardware test
Internal self return test
5
6
7
2) ReS-232 connector
For connecting RS-232 connector for peripheral equipment
3) STATION No. (Factory setting:1) : Station setting switch
Station numbers can be set inside the same network.
When there is a setting error, the "ERR" LED will come on in red.
6) RESET switch
Resets the remote I/O station hardware. 1
7) Coaxial connector
For connecting F-type connector for coaxial cable.
Setting
Contents
Setting Contents
25 Mbps
used
1) LED indicator
section
1) LED indicator
section
3) (Left side face)
3)
2)
2)
6)
5)
5)
6)
Optical loop module
Coaxial cable bus module
4)
4)
7)
0
8
F
7
D
5
C
4
B
3
9
1
RS-232
MODE
RESET
IN
OUT
QJ72LP25-25
0
5
9
4
8
3
7
2
6
1
0
5
9
4
8
3
7
2
6
1
STATION NO.
X10
X1
QJ72BR15
0
8
C
4
0
5
0
5
MODE
STATION
X10
X1
NO.
RESET
RS-232
1: When resetting the system, press and hold the RESET switch for a second or more. If the pressing
time is too short, the system may not be reset normally. If the system is not reset normally, try reset
operation again.
POINT
1) There can be no duplication of station numbers in the same network.
2) Setting can be done regardless of station sequence. However, if a number is to
be left empty, sting a reserved number.
3) Set the mode setting switches in the same position on all network modules.
To Next Page
