3 SPECIFICATIONS
[W output transmission delay time (T
DB2
)]
[Remote master station scan time (Sm) > link scan time (LS)]
T
DB2
= (Sm + αm)
+
LS + T
RBF
[ms]
LS
T
RBF
T
DB2
Buffer memory
MOV D100 W100
Intelligent function
module
Remote master station
Link scan time
Remote I/O station
0E
Sm
α
m
0E
Sm
α
m
0E
Sm
α
m
0E
Sm
α
m
0E
Sm
α
m
0E
Sm
0: 0 step
E: END step
LS LS LS LS
[Remote master station scan time (Sm) < link scan time (LS)]
T
DB2
= (Sm + αm) round up [LS/(Sm + αm)] + LS + T
RBF
[ms]
LS
T
RBF
T
DB2
Buffer memory
MOV D100 W100
0
Sm
LS LS
Intelligent function
module
Remote master station
Link scan time
Remote I/O station
0: 0 step
E: END step
0E
Sm
αm
0E
Sm
αm
0E
Sm
αm
0E
Sm
αm
0E
Sm
αm
0E
Sm
αm
Sm
αm
LS
T
RBF
round up
: Remote master station scan time
: Remote master station link refresh time
: Link scan time
: Intelligent function module buffer memory refresh time
: Round up the decimal point of the result operation [LS/(Sm + αm)]
POINT
When the Secured data send/receive setting is enabled, the transmission
delay time (T
DB2
) is calculated as follows:
• [Remote master station scan time (Sm) > Link scan time (LS)]
T
DB2
= (Sm + αm) + LS + T
RBF
[ms]
• [Remote master station scan time (Sm) < Link scan time (LS)]
T
DB2
= (Sm + αm) x round up[LS/(Sm + αm)] x 2 + LS + T
RBF
[ms]
