3 - 42 3 - 42
MELSEC-Q
3 SPECIFICATIONS
(3) Link refresh time
The link refresh time (CPU module end processing time extension) is calculated
as shown below.
• Link device allotment points
• Type of CPU used
[Remote master station refresh time (αm)]
α
m
= KM1 + KM2 {LB + LX + LY + SB + (LW 16) + (SW 16)} /16 + α
E
[ms]
α
E
= KM3 {LB + LX + LY + (LW 16)} /16
α
m
LB
LW
LX
LY
SB
SW
α
E
: Remote master station link refresh time
: The total number of link relays (LB) that station refreshes 1
: The total number of link registers (LW) that station refreshes
1
: The total number of link inputs (LX) that station refreshes
1
: The total number of link outputs (LX) that station refreshes 1
: Number of special relays (SB) for link
: Number of special register (SW) for link
: File register (R, ZR) transmission time on memory card
2
KM1, KM2, KM3 : Constants
1) When a network module is connected to main base unit
Constant
CPU type
KM1
KM2
(
10
–3
)
KM3
( 10
–3
)
QnCPU 0.30 0.48 0.60
QnHCPU, QnPHCPU,
QnPRHCPU
0.13 0.41 0.53
2) When a network module connected is to extension base unit
Constant
CPU type
KM1
KM2
(
10
–3
)
KM3
( 10
–3
)
QnCPU 0.30 1.20 1.32
QnHCPU, QnPHCPU,
QnPRHCPU
0.13 0.97 1.09
1: The total number of points for the range that is actually refreshed.
(Includes unused areas as well)
2: Becomes the total when simultaneous transient transmissions are
performed from multiple stations.
Remote I/O station link refresh time (αr)
The remote I/O station link refresh time (αr) does not affect transmission delay
time
