Before Using This Product
This chapter explains the product's characteristics, part names and functions, basic operations, and
the settings that must be congured prior to measurement.
1.1
Product Capabilities
This product is a measuring instrument that makes measurements by vertically moving a part called a
probe into contact with a specic point, and calculating the height of that point. Because the measure-
ments are obtained from the probe's position, this product can measure the inner diameter of holes
and the outer diameter of cylinders as well.
Measurement
point
Bring the probe into contact with the point you want to measure (
①) , and read the displayed mea-
surement (②).
①
②
