8
1 Before Using This Product
No. 99MAF600B
1.3.3 Moving the Main Unit
When moving the main unit on the surface plate, grab the base with your right hand and the carrier
grip with your left hand.
For QMH-600BX/QMH-350BX/QMH-24"BX/QMH-14"BX, pressing the air-oat switch on the tip of the
carrier grip causes air to make the main unit oat, allowing you to move it smoothly above the surface
plate.
Do not move the product by grabbing parts other than the base or carrier grip. Doing so can negatively affect
measurement accuracy and the product itself.
If using the air-oat function:
• Measuring with the air-oat function active can cause measurement errors.
• Clean the surface plate in advance.
• Use a surface plate of Class JIS1 or higher. If the surface plate is scratched or uneven, the specied perfor-
mance may not be achieved.
• Use a rigid surface plate. If the surface plate warps under the weight of the product, the product may not
oat.
To Next Page
