Mitutoyo QM-Height Series User Manual

63
6Specications
No. 99MAF600B
6.5
Optional Accessories
Part No. Accessory name
y Depth measuring probe
12AAC072 Depth probe
y Interchangeable contact point for ø5 stepped probe
957261 ø2 ball contact point (coaxial type)
957262 ø3 ball contact point (coaxial type)
957263 ø4 ball contact point (coaxial type)
957264 ø14 disk contact point
957265 ø20 disk contact point
12AAA788 ø4 ball contact point (eccentric type)
12AAA789 ø6 ball contact point (eccentric type)
y Special holder, special probe
12AAA792 Holder for dial gauge
12AAA793 Long holder
y AC adapter
06AFZ950JA
or 06AEG180JA
AD620JA (for Japan/U.S.)
06AFZ950D
or 06AEG180D
AD620D (for EU)
06AFZ950E
or 06AEG180E
AD620E (for England)
06AFZ950K
or 06AEG180K
AD620K (for Korea)
06AFZ950DC
or 06AEG180DC
AD620DC (for China)
y Digimatic connection cable
936937 1 m
965014 2 m
y Others
05HZ A143 9 x 9 adapter (the following clamp is required)
05GZA033 Clamp (for 9 x 9 adapter)
05HZ A144 6.35 x 12.7 adapter (the following clamp is required)
901385 Clamp (for 6.35 x 12.7 adapter)
02AZE990 U-WAVE mounting plate
05HZ A173 Scriber
*1
*1
The scriber is used for making measurements. It cannot be used for markings.
NOTICE
The gauge blocks may be required for zero-setting depending on the probes and contact points to be used.
