3
1 Before Using This Product
No. 99MAF600B
①
Head cover
⑩
Clamp screw
Fixes the rotational movement of the probe
up/down wheel.
②
Display unit
Displays measurements and any messages.
⑪
Float amount adjustment screw (QMH-
600BX/QMH-350BX/QMH-24"BX/QMH-
14"BX only)
Adjusts the amount of airow used in the air-
oat function. Turning the screw right increas-
es airow, and turning it left reduces airow.
③
Micro USB connector (AB receptacle)
*1
This port is for connecting your PC with a
micro USB cable.
⑫
Label
Contains the code number of this product.
④
Digimatic output connector
*1
This port is for connecting the optional
Digimatic mini-processor.
⑬
Base
Contact surface used when installing the
main unit on the surface plate. Grip the base
when moving the main unit along the surface
plate.
⑤
DC jack
*1
This jack is for connecting the optional AC
adapter.
⑭
Carrier grip
Hold the carrier grip when moving the main
unit along the surface plate.
⑥
Battery case
A case for inserting the batteries.
⑮
Probe clamp knob
Clamps the probe so that it does not come
out.
⑦
Air-oat switch (QMH-600BX/QMH-350BX/
QMH-24"BX/QMH-14"BX only)
This switch uses the air-oat function to make
the main unit oat.
Measuring with the air-oat function active can
cause measurement errors
⑯
Probe
Used for obtaining measurements. Touch the
ball on the tip of the probe to the workpiece to
obtain the measurements.
⑧
Probe up/down wheel
The probe moves up and down as the wheel
is turned left and right.
⑰
Clamp knob
Fixes the movement of the probe.
⑨
Probe ne adjustment knob
Pulling the knob and turning it moves the
probe slowly.
*1
During use, we recommend securing the cable with the included cable clamp.
To Next Page
