5
1 Before Using This Product
No. 99MAF600B
①
Shows the result of the tolerance judgment.
Tips
For details, "3.2 Judging the Tolerance"
(page 38)
⑦
Changes the setting for units between inches
and millimeters (only on models that support
inches).
②
Turns the power on or off.
⑧
Sets a value for the reference.
③
Measures the inner diameter.
Tips
For details, "2.3 Measuring the Inner Diame-
ter" (page 21)
⑨
Changes numbers and settings. Press
to conrm an operation.
Tips
• Press and hold to reverse the count-
ing direction: Moving the probe upwards
decreases the value, and moving the probe
downwards increases the value. Press and
hold the button again to return to normal.
• If you reversed the counting direction, follow
the procedure in
"1.4.1 Reference Setup"
(page 10) to reset the reference.
④
Measures the outer diameter.
Tips
For details, "2.4 Measuring the Outer Diame-
ter" (page 25)
⑩
Cancels an operation.
⑤
Measures the maximum, minimum, and dis-
placement values (maximum – minimum =
displacement) of a horizontal plane.
Tips
For details, "2.5 Measuring the Plane Dis-
placement (Plane Scanning Measurement)"
(page 29)
⑪
Used to change settings for a specic appli-
cation, such as changing the measurement
resolution.
Tips
For details, "3 Specic Usage Applications"
(page 31)
⑥
Switches the reference setting between ab-
solute measurement (ABS) and incremental
measurement (INC).
⑫
Holds a measurement in the display and
outputs the measurement results to external
devices.
Tips
For details, "3.5 Holding the Displayed
Measurement Results" (page 44) and "3.9
Outputting Measurement Results to an External
Device" (page 47)
To Next Page
