18
2 Basic Measuring Methods
No. 99MAF600B
2
Bring the ball of the probe into contact with surface a1 until a beep sound is made.
Maintain contact with the ball.
a1
Top surface measurement Bottom surface measurement
» When the measurement is complete, [H] and the measured value are displayed on the LCD screen.
Tips
If the product is connected to any external devices, the measurement results will be automatically output. For
details, "3.9 Outputting Measurement Results to an External Device" (page 47)
3
Conrm the measurement.
Top surface measurement Bottom surface measurement
Tips
The value next to [ZP] displayed in the bottom row of the LCD screen shows the difference between 2 measure-
ments. For details, "3.1 Calculating the Difference Between 2 Measurements" (page 31)
To Next Page
