Configuration Guide
Leviton Dimensions 4000 Series Architectural Lighting Controller
Page 14
OPERATION SETUP QUICK START OVERVIEWCONFIGURATION
Devices with Channel Control only (D4200)
Setting up units with control and dimmers require a few basic
steps which when followed will ensure success of your lighting
control system:
Step 1: Confirm all connections have been completed.
• Network connections are required
• Connection to adequate power supply is required
• Lock/Occ input is an optional connection
Step 2: Confirm network is terminated correctly, reference
installation guide for additional information.
Step 3: Complete all “System Layout Charts” on page 68 to
confirm a clear understanding of all system and
configuration requirements.
Step 4: Review “Navigating the Menus” on page 49
Step 5: Power up unit
Step 6: Perform “Power Up Initialization” on page 16 or review
“Setting the Network ID” on page 20
Step 7: Perform setup of other network devices, dimmers, etc.
Step 8: Confirm this device is patched to the correct channels.
Reference “To Assign Zones, consecutively, from a
Starting Channel Number:” on page 25.
Step 9: Push the MAX button
• CONFIRM that all loads controlled by this
device go to full. If they DO,
CONGRATULATIONS! You have made it a
long ways towards a successful
installation. If they DO NOT go to full,
please reference the troubleshooting
section on page 70 for additional
troubleshooting steps.
Step 10: Slave any remote/entrance stations to this device.
(p.42)
Step 11: Configure the clock - Set the date & time. See
“Configure the Clock” on page 52.
Step 12: If scheduling events around sunrise or sunset, setup
the astronomical time clock on page 53.
Step 13: Record your scenes, see “Recording a Scene” on
page 53.
