Configuration Guide
Leviton Dimensions 4000 Series Architectural Lighting Controller
Page 42
OPERATION SETUP QUICK START OVERVIEWCONFIGURATION
Connecting Entrance Stations
Most systems involve the use of not only a master station but
entrance stations as well. The D4000 system entrance stations
must:
• be “slaved” to the master to station which they remotely
control, and,
• have a unique network address.
To connect an entrance station to the system:
Step 1: Determine the network id for the entry station
Step 2: If already installed, remove the entry station from the
wall and unplug the network cable
Step 3: Set the Network ID dipswitch to the Network ID of the
master station
to which this device should be slaved
Step 4: Hold down the upper left button on the device and
plug in the network connector
• After approximately 10 seconds, the green
LED’s will blink. Once this occurs, the id
has been successfully programmed and
you can move on to the next step.
Step 5: Unplug the network connector
Step 6: Set the Network ID dipswitch to the appropriate
network id of the entry station
Step 7: Plug the network cable back into the device and install
the unit into the wall.
