Configuration Guide
Leviton Dimensions 4000 Series Architectural Lighting Controller
Page 62
OPERATION SETUP QUICK START OVERVIEWCONFIGURATION
Scheduled Events
Your device can be programmed for up to 64 possible Events,
numbered E01 through E64. An event consists of any of the
following functions:
• Recall Scenes
• Recall Max or Off
• Start/Stop/Resume Sequencer
• Goto a sequence step
• Enable/Disable a photocell connected to an NPC or a-2000
Creating & Editing Scheduled Events
To edit the schedule:
Step 1: Press the Menu/Cancel button.
Step 2: Press the Up and Down buttons until EDIT
SCHEDULE? flashes on the LCD display.
Step 3: Press the Select/Save button.
• The current Event number flashes.
• Scheduled Events are displayed in the following form:
Step 4: Press the Up and Down buttons to scan
through the possible Events.
Step 5: Press the Select/Save button to select the Event you
want to edit.
Step 6: Use Left Right buttons to move between
fields on the screen, and Up Down buttons
to change the values.
• Schedule Time is the time at which this event will occur.
• Set to Time of day, or,
E01: 07:12A S01
SMTWT-S BW:NO
timenumber
ActionScheduledEvent
Enabled
Days of Week
Blink
Warn
