Page 19
Accessing the Configuration Menus
All configuration is done through the menus of the Dimensions
4000 series controller. Menus are accessed by pressing the
“Menu” button and navigating with the Up/Down arrows and the
SELECT key.
Operation & Configuration Menus
There are two levels of configuration menus, Basic & Advanced.
Basic mode is always available. To enter advanced mode, follow
the procedure below:
Step 1: Push the MENU button until the display reads the
current day and time
Step 2: Push and Hold the MENU button for approximately 10
seconds until the display reads:
Step 3: IMMEDIATELY release the menu button, then press
and hold ZONE 4 DOWN for several seconds until the
display reads as follows:
When the above 3 steps have been successfully completed, the
menu structure will be expanded to included both the operation
and configuration mode menus.
PLEASE WAIT
REBOOTING
ADVANCED MENUS
ACTIVE
