Page 47
• To rapidly increase or decrease the lighting levels, press
and hold the button.
The approximate lighting levels for each Zone are represented by
the Zone level indicators. The lighted Scene button goes dark and
the LCD display shows MANUAL MODE after the Master Up or
Down button is pressed. You can record these new values for
the Scene if you prefer the new lighting levels.
Since levels in all assigned Zones increase or
decrease by the same amount, lighting levels
eventually become the same in all Zones when you
press the Master Up or Down buttons. As
each Zone reaches its maximum or minimum level, it
stays at that level while the other Zones catch up.
Individual Lighting Levels
Open the cover to access the lighting level buttons. Using the
Zone Up and Down buttons, adjust the individual lighting
levels for each of the zones. The approximate lighting level for
each Zone is represented by the Zone level LED indicators. The
exact percentage for each Zone is shown on the LCD display.
There is an indicator (P1 or P2 or P3 or P4) in the
upper right corner of the display to inform you what
page of zones you are currently in. Press the Page
Zones button to alternate the Zone numbers
between P1 (1-8) P2 (9-16), P3 (17-24) and P4 (25-
32). When in P3 or P4 the Zones LED indicators will
not light)
• To increase or decrease a Zone lighting level by one
percent, momentarily press any Zone Up or Down
button.
• To rapidly increase or decrease a Zone lighting level, press
and hold the button.
The lighted Scene buttons go dark and the LCD
display shows MANUAL MODE after any Zone Up
