Configuration Guide
Leviton Dimensions 4000 Series Architectural Lighting Controller
Page 50
OPERATION SETUP QUICK START OVERVIEWCONFIGURATION
• Page Zones. Alternates the Zone numbers between 1-8
and 9-16, 17-24 and 25-32. The LCD will indicate which
Page you are currently in. P1 refers to Zones 1-8, P2
indicates Zone 9-16, P3 indicates Zone 17-24 and P4
indicates to Zones 25-32 are active.
The Zone number LED’s do not light up on P3 or P4
Enabling the Sequencer
This function globally enables or disables the sequencer.
To enable or disable the sequencer:
Step 1: Press the Menu/Cancel button.
Step 2: Press the Up and Down buttons until
SEQUENCER= flashes on the LCD display.
Step 3: Press the Select/Save button.
• The
OFF
or
ON
value flashes.
Step 4: Press the Up and Down buttons to change
the value.
• Note: Press
Clear
to change the value to
OFF
.
Step 5: Press the Select/Save button to save the value.
Step 6: Press the Menu/Cancel button to exit this menu.
Breakfast P1
S01 TUE 04:29p LE
Page Number - P1 = Zones 1-8
Days of week
Scene #
Indicates Schedule is active
P2 = Zones 9-16
Scene Name
Indicates Station is Locked
P3 = Zones 17-24
P4 = Zones 25-32
To Next Page
