Page 35
Miscellaneous Settings Menu
The miscellaneous settings menu has settings which aff
ect the
general oper
ati
on of the panel. This menu is only available fr
om
the adv
anced menus (see page 19) and has a structure as
follows:
All of the settings on this menu can be changed using the
following process:
OFF
S18 THU 08:48P
MENU
MISC SETTINGS
MISC SETTINGS
READBACK REQ: ON
MISC SETTINGS
BUMP MODE: MAX
MISC SETTINGS
BACKLIGHT:DIMMED
MISC SETTINGS
LOCK: ENABLED
MISC LOCK/OCC
EVENT: S01
MISC UNLK/UNOCC
EVENT: OFF
MISC SETTINGS
TIME MASTER: AUTO
MISC SETTINGS
NTWRK COMPAT:NEW
MISC SETTINGS
BW OVRD: 30MIN
MISC SETTINGS
MAX ZONES: 16
MISC SETTINGS
FACTORY DEFAULTS
MISC SETTINGS
IR PORT: ENABLED
