Configuration Guide
Leviton Dimensions 4000 Series Architectural Lighting Controller
Page 6
OPERATION SETUP QUICK START OVERVIEWCONFIGURATION
Installation Recommendations
For best results using the Dimension 4000 Architectural Lighting
Controllers, follow these recommendations:
1: Plan the system before beginning the installation:
• Device location and primary purpose
• Determine which controllers are controlling which
dimmers
• Determine location and function of remote stations
• Consider power supply, wire size, run length, load
requirements
• Consider any regularly scheduled events.
2: Follow the installation instructions covering physical
installation, connections and wring of your device
3: Use the information in this “setup” section of this guide for
initial setup, and the “configuration” section for regular
programming.
4: When configuring a system with multiple devices it’s helpful
to connect them one at a time so that any problems are
isolated as they arise. For example:
• First install & configure master stations,
• Confirm that the master station is working correctly,
• Install first entry station (or device), configure it, and
confirm that it’s working correctly
• Repeat until all device are installed
