Configuration Guide
Leviton Dimensions 4000 Series Architectural Lighting Controller
Page 16
OPERATION SETUP QUICK START OVERVIEWCONFIGURATION
Power Up Initialization
Upon the initial power up (and anytime the network id is set to 0)
a special power up initialization menu is displayed which allows
you to configure the following:
• Network ID
• Device Name
These settings must be set prior to any further configuration or
use of this device.
Network ID
The network id is the address of this “node” on the network. The
ID for every device on the network must be unique.
Enter a unique ID number for this station in the space provided
this space.
When you’ve finished entering the network ID, press the down
arrow to advance to the next setting.
Device Name
Each device may have a unique name. The default name is a
derivation of the model number, however, it is recommended that
you give it a unique name which makes more sense to you.
Examples of good names are: “South Wing”, “Room 221”, “Main
Office”, etc.
Enter a network name. Names can be entered using the UP/
DOWN/LEFT/RIGHT arrows, or you can use the Zone
Information, Up/Down, and number keys to enter alphanumeric
characters.
EDIT NETWORK
ID=001 MASTER
EDIT NETWORK
NAME=D4206 1
To Next Page
