Configuration Guide
Leviton Dimensions 4000 Series Architectural Lighting Controller
Page 24
OPERATION SETUP QUICK START OVERVIEWCONFIGURATION
Zone to Channel Patch
Each device, depending on the model, has a number of different
Zones. These zones give you the ability to control both local
dimmers, if your device has them, and also possibly remote
dimmers via a network channel. The network channel, or simply
channel for short, is the location on the network where zone level
information is stored for retrieval by devices like dimmers, relays,
etc. The Zone/Channel patch establishes the relationship
between the zones and the network channel.
There are two ways to set the patch, one which assigns a
channel to each zone, or, the short cut method of simply setting
the Starting Channel Number for Zone 1 and the rest of the
zones follow sequentially. Setting the patch from a starting
channel number should be used when all of the zones on your
device will be controlling consecutive network channels. This is
the most common configuration.
It is helpful to complete the zone patching
chart which can be found on page 69.
The advanced topic of “Groups” is
discussed later on in this guide,
however, the configuration of such is
covered here.
