Configuration Guide
Leviton Dimensions 4000 Series Architectural Lighting Controller
Page 34
OPERATION SETUP QUICK START OVERVIEWCONFIGURATION
To set the starting channel number on a device with only
dimmers:
Step 1: The display should be steady indicating the starting
channel number. If it is flashing, push and hold the up
button for approximately 3 seconds. The display then
will be steady.
Step 2: Use the Up/Down arrows until the desired starting
channel number is shown.
Step 3: Push and hold the Down/Set button for approximately
three seconds until the number start rapidly flashing.
This indicates that the new value is being saved.
There are many other configuration parameters for
a remote dimmer. These should be set from a
D4206 or D4200 master station. Reference
“Configuration of Dimmers at another panel” on
page 31
