Configuration Guide
Leviton Dimensions 4000 Series Architectural Lighting Controller
Page 38
OPERATION SETUP QUICK START OVERVIEWCONFIGURATION
it’s time from the master. If no master is detected, then
this device will establish itself as the master time clock for
the network. When a device is in AUTO mode, anytime a
new MASTER time clock broadcast is detected, it will
automatically demote itself to receive only mode.
Network Compatibility
This setting is only for use when using a new device with old
network devices. The default setting is NEW and should remain
as such unless directed to change the value by Technical
Services.
IR Port
The IR port can either be enabled or disabled by this setting.
Valid values are as follows:
• Enabled: The IR port will receive and process IR signals
• Disabled: The IR port will ignore all IR signals.
LOCK/OCC Input Behavior
The Lock/Occ input can be used to trigger a scene according to
either the LOCK OR OCC input at the rear of the device, and,
optionally lock the user interface. There are three menu options
which effect this feature, each setting is as described below:
• Active Scene
indicates the event/scene which should be recalled when
the input goes active. If the input used is the OCC input,
an active input is indicated by the input received +24Vdc.
If the input used is the LOCK input, an active input is
indicated by the input being connected to common. Valid
settings are:
MISC: LOCK/OCC
EVENT: S01
