Chapter Two: Installation Interface Cables
11
Interface Cables
As of January 1, 1996, most products shipped to the European Community must comply with the
EMC Directive 89/336/EEC, which covers radio frequency emissions and immunity tests. In
addition, as of January 1, 1997, some products shipped to the European Community must also
comply with the Product Safety Directive 92/59/EEC and Low Voltage Directive 73/23/EEC,
which cover general safety practices for design and workmanship. MKS products that meet these
requirements are identified by application of the CE Mark.
To ensure compliance with EMC Directive 89/336/EEC, an overall metal braided shielded cable,
properly grounded at both ends, is required during use. No additional installation requirements
are necessary to ensure compliance with Directives 92/59/EEC and 73/23/EEC.
Note
To order a metal braided shielded cable, add an “S” after the cable type
designation. For example, to order an overall metal braided shielded
cable to connect to a 246 unit, use part number RCB259S-5-10. Use part
number RCB259-5 to order a non-shielded cable.
Interface Cables
To Connect To . . . Use Cable . . .
Type 246, 247, or 113 set point/display module RCB259S-5-10/
RCB259-5-10
Type 647 or 167 set point/display module
(includes open and close lines)
RCB147S-1-10/
RCB147-1-10
Table 2: Interface Cables
