Environmental Specifications Appendix A: Product Specifications
52
Environmental Specifications
Operating Temperature Range
0 to 50 C (32 to 122 F)
Storage Temperature Range
-20 to 80 C (-4 to 176 F)
Storage Humidity Range 0 to 95% Relative Humidity, non-condensing
Trip Point Specifications
Trip Points
Rated Current
State
Hysteresis
Status LEDs
Settings
Two open collector transistors, adjustable from 0 to 100%
full-scale
30 VDC/250 mA
On above or below trip point; jumper selectable
3% full-scale (factory set)
Green when the transistor is on
0 to 5 Volts corresponds to 0 to 100 % full-scale
