MKS 640B - Figure 7: Bottom View of the down Port 640; Figure 8: Bottom View of the down Port Seals

Dimensions Chapter Two: Installation
20
3.622+0.015
(92+
0.38)
0.591+
0.005
(15+
0.12)
1.181+
0.00
5
(30+0.12)
4.14+
0.02
(
105.0+0.5
)
Figure 7: Bottom View of the Down Port 640
Figure 8: Bottom View of the Down Port Seals
