MKS 647C - System Setup; RS232 Setup

647C 3. Functionality
29
3.8 System Setup
3.8.1 RS232 Setup
MGC 647C V3.0
BAUDRATE 9600
PARITY ODD
BITS 8 bit
STOPBITS 1 bit
HANDSHAKE NONE
RS232 STATUS -- -- --
LCD VIEW ANGLE [°] 023
LCD ON TIME [min] 010
HOST MODE C-MODE
RESET EXEC
00 ERRORS FLOW OFF INPUT DIRECT
Figure 21
The 647C implements a standard V24, RS232 interface with standard parameters.
3.8.1.1 Baudrate
The baudrate defines the transfer speed of characters on the line. The transfer rate of commands
and data is determined by this baudrate and by the processing speed of 647C. The first 30
commands will be directed to a buffer at maximum speed, while the transfer of further commands
is controlled by a handshake protocol. The baudrate must fit to the baudrate of the host computer.
- supported baud rates:
50, 75, 110, 150, 300, 600, 1200,
1800, 2000, 2400, 3600, 4800, 7200, 9600 Baud
3.8.1.2 Data Link Parameters
The data link parameters must fit to setup of the host computer. Change it according to the setup of
the host.
- word length
7 bit
8 bit
- parity
NONE
EVEN
ODD
stop bits
1 bit
2 bit
