Mobatime DTS 4801.masterclock - Page 32

© MOBATIME 32 / 120 800652.11
The six different DCF active code modes:
Mode 1
U
0
+
-
t
1s 2s 3s
Mode 2
U
0
+
-
t
1s 2s 3s
Mode 3
U
0
+
-
t
1s 2s
3s
Mode 4
U
0
+
-
t
1s 2s 3s
Mode 5:
U
0
+
-
t
1s 2s 3s
Mode 6
U
0
+
-
t
1s 2s 3s
Mode 1/6, 2/5, 3/4 are equal. Their polarity only depends on how the line is connected
to the DTS 480x.masterclock. The signal forms shows the voltage measured from
terminal a to terminal b (refer to annex A).
