© MOBATIME 89 / 120 800652.11
9.3.5 Alive Notification [dts480xAlive]
Sent out in a configurable interval.
This Notification is always sent out, as soon as SNMP and the alarm traps are
activated and a destination address is configured.
The Notification sent out contains the following data:
Field Type Size Description Example
dts480xSysStatus Unsigned Int 4 Bytes
Contains the internal
system status
66309
dts480xSysAlarms Byte Array 8 Bytes
64 Bit Alarm flags
1.Byte Bit 0..7
2.Byte Bit 8..15
::
8.Byte Bit 56..63
FFF870FF.FFFFFFFF
¦ ¦ ¦
¦ ¦ 5.Byte
¦ 2.Byte
1.Byte
9.3.6 Alarm Notification [dts480xAlarm]
Sent out if alarm status changes, i.e. Notification is sent out when an alarm flag is set
or deleted.
This Notification is always sent out, as soon as SNMP and the alarm traps are
activated and a destination address is configured.
The Notification sent out contains the following data:
Field Type Size Description Example
dts480xTrapAlMsgErrorNr Byte 1 Bytes No. of the alarm bit (0..63) 8
dts480xTrapAlMsgErrorState Byte 1 Bytes
0 = alarm bit was deleted
1 = alarm bit was set
1
dts480xTrapAlMsgErrorTime
Unsigned
Int
4 Bytes
PC-time in seconds since
01.01.1970 00:00:00
946684805
dts480xTrapAlMsgErrorText Text 59 Bytes Error text
Line current too
high
