2.4 Delivered Parts, Components and Dimensions - D12D Stan-
dard
2.4.1 Delivered Parts and Components - D12D Standard
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com
36/132
D12 Camera Manual Part 1
Make sure to check the
delivered parts!
Item Count Part Name
1.1
1.2
1
2
Camera housing
Lens
1.3
1.4
1.5
1.6
2
2
Lens mount
Lock ring
2
8
Ribbon cable
Cable clamp
1.7
1.8
1.9
1.10
1
2
Cable cover
Dome; 1x tinted, 1x transparent
1
1
Outer shell
Ethernet cable
1.11
1.12
1
1
Allen wrench 3 mm
Custom tool with magnet
D12D Standard
Camera housing (item1.1)
Allen wrench 3mm
(item1.11)
Dome (item1.8),
1x transparent, 1x tinted
Cable cover (item1.7)
Ethernet cable (item1.10)
Custom tool with mag-
net (item1.12)
Outer shell (item1.9)
2 lens mounts (item1.3)
2 lenses (item1.2)
2 lock rings (item1.4)
Mounting Supply
Item
M.1
Count
3
Part Name
Dowels 10 mm
M.2
M.3
3
3
Stainless steel washers Ø 9mm
Stainless steel wood screws with hex head 8x70mm
